Frame: | Lite II - Hydroformed 6066 triple butted aluminium with integrated battery chamber, mounts for mudguards, rack and kickstand. 9mm QR axle standard, BSA BB standard. Max. tyre size 700 x 45c without mudguards, 700 x 42c with mudguards, 27.5 x 47c |
Fork: | Merida Silex CF2; Tapered; carbon, Max. tyre size: 700 x 42c without mudguards, 700 x 35c with Mudguards. Max 27.5" x 50c |
Headset: | Merida 8158 |
Stem: | Merida Team CC III; aluminium; 31.8mm diameter; -6 degree rise; length: 80mm all sizes |
Bars: | Merida Expert GRII; aluminium; 400mm (XS/S), 420mm (M), 440mm (L/XL) |
Front Brake: | Shimano GRX400 2 piston hydraulic disc brake caliper with Shimano RT10 160mm rotor |
Rear Brake: | Shimano GRX400 2 piston hydraulic disc brake caliper with Shimano RT26 160mm rotor |
Brake Lever: | Shimano GRX400 |
Front Mech: | Shimano GRX400 |
Rear Mech: | Shimano GRX400 |
Shifters: | Shimano GRX400 |
Speed: | 20 |
Rims: | Merida Comp SL; 17mm inner rim width; 22mm rim depth; aluminium |
Front Hub: | Shimano HB-TC500; 100 x 12mm; 28 Spokes; Centerlock |
Front Tyre: | Maxxis Rambler; 700 x 40C; Kevlar bead, folding; EXO |
Rear Tyre: | Maxxis Rambler; 700 x 40C; Kevlar bead, folding; EXO |
Seat Post: | Merida Expert; aluminium; 30.9mm diameter; in-line |
Saddle: | Merida Comp SL; V-mount |
Chainset: | Shimano GRX600; 46-30 tooth chainset with 170 mm-XS/S/M, 175 mm-L/XL crank |
Bottom Bracket: | Shimano RS500 BSA |
Chain: | KMC e10 |
Cassette: | Shimano CS-HG50; 11-36 teeth; 10 speed |
Pedals: | VP Components - VPE-891 |
Battery (Wh): | Mahle ix250Wh Battery Pack |
Motor: | Mahle X30 Hub motor, 40Nm |
