Sorry, this product is no longer available.
| Frame: | Arcadex PRO Disc Brake Specification: Flat Mount 140/160. Bottom Braket Standard: PressFit 86.5 X Ø41. Rear Axle: thru12 OLD (Over-Locknut-Dimension): 142 mm. Rear Derailleur: SRAM UDH Hanger type. Material: Epoxy - SM Carbon Fiber Composite |
| Fork: | Bianchi Arcadex Fork Disc Brake Specification: Flat Mount 140/160 Front Axle: thru12 OLD (Over-Locknut-Dimension): 100 mm Tire Clearance: ETRTO 622-50 mm Steer tube Diameter: 1 1/8" Material: Epoxy - SM Carbon Fiber Composite |
| Headset: | Bianchi Custom Acros ICR (Internal Cable Rounting) Spacers:5 mm x1,10 mm x3 |
| Stem: | Velomann AICR Alloy Rise: -2° Steerer Diameter: 1-1/8" (28.6 mm) HB interface Diameter: 1-1/4" (31.8 mm) Stem Lengths: 80 mm - XS(47), 90 mm - SM(51), 100 mm-MD(55), 110 mm-LG(58),120 m -XL(61) |
| Bars: | Velomann Gravel ICR Alloy Flare: 16° | Drop: 130 mm | Reach 70 mm Interface Diameter: 1 1/4" (31.8 mm) HandleBar Widths: 400 - SX(47) SM(51), 420 - MD(55) LG(58), 440 -XL(61) |
| Front Brake: | Shimano Hydraulic Brake, BR-RX820 |
| Rear Brake: | Shimano Hydraulic Brake, BR-RX820 |
| Rear Mech: | Shimano GRX 822 RD-RX822, SGS Maximum Cassette Sprocket 51T |
| Shifters: | Shimano GRX 820 ST/BL-RX820 |
| Speed: | 12 |
| Rims: | Velomann Terbium clincher and tubeless ready Rim Diameter: 700C Material: Carbon Rim Height: 30 mm Inner Wigth Channel: 25 mm |
| Front Tyre: | Pirelli Cinturato™ GRAVEL M Classic, 45-622 tan sidewall |
| Rear Tyre: | Pirelli Cinturato™ GRAVEL M Classic, 45-622 tan sidewall |
| Seat Post: | Velomann Carbon UD SeatPost O.D: Ø27.2 mm | Seatpost lengths: 300 mm- SX(47), 350 mm-SM(51) MD(55), 400mm-LG(58) XL(61)" |
| Saddle: | Velomann MITORA 149 H1 cover: soft touch | padding: foam | shell: nylon carbon rails: Aisi Steel | lenght: 250 mm | width: 149 mm weight: 230g ± 2" |
| Chainset: | Shimano GRX 820 FC-RX820-1,40T Crank Length: 170 mm-XS(47)-SM(51), 172.5 mm- MD(55)-LG(58), 175 mm-XL(61) |
| Bottom Bracket: | Shimano SM-BB72-41B, press fit |
| Chain: | Shimano CN-M7100 |
| Cassette: | Shimano CS-M7100-12 speed, 11-51T Driver body Interface: MicroSpline |
What are the delivery costs?
We offer Free UK Mainland Delivery on all orders over £20. Products shipped to outlying UK regions are excluded from free shipping.
Standard delivery is normally 2 - 5 working days.
Please view our delivery page for full information on UK and international delivery costs.
The Arcadex range perfectly combine an emotional communion with nature, and the exhilarating rush of Bianchi racing DNA.
Bianchi Gravel range best suits the needs of riders looking to enjoy their time in the saddle and tackle the greatest variety of rides. Every surface becomes rideable and every adventure possible.
Occasionally, without notice, manufacturers change product design and/or specifications.
