Heritage Red/Grey
XXS
Built & dispatched in 4-5 working days
ID: 272353-1003647
£2,300.00
Add to basket
Heritage Red/Grey
XS
Built & dispatched in 1-2 working days
ID: 272353-1003648
£2,300.00
Add to basket
Heritage Red/Grey
S
Built & dispatched in 1-2 working days
ID: 272353-1003649
£2,300.00
Add to basket
Heritage Red/Grey
M
Built & dispatched in 1-2 working days
ID: 272353-1003650
£2,300.00
Add to basket
Heritage Red/Grey
L
Built & dispatched in 4-5 working days
ID: 272353-1003651
£2,300.00
Add to basket
Heritage Red/Grey
XL
Built & dispatched in 4-5 working days
ID: 272353-1003652
£2,300.00
Add to basket
| Frame: | CF3 V carbon, race geometry. Internal cable routing, 142 x 12mm axle standard, flat mount rear brakes with Disc Cooler, Pressfit 86.5 BB standard, 1 1/2" to 1 1/4" headtube. Max tyre size - 30c |
| Fork: | Scultura CF3 Disc; full carbon; Max tyre size: 700 x 30c - Disc cooler technology |
| Headset: | Merida Team SL (OP-203 neck) |
| Stem: | Merida Expert SL 2PII; aluminium; -9 degree rise -Length - 90mm (XXS-XS), 100mm (S), 110mm (M-L), 120mm (XL) |
| Bars: | Merida Expert SLII; aluminium; 380mm(XXS-XS-S), 400mm (M-L-XL) |
| Front Brake: | Shimano 105; Hydraulic disc brake caliper with Shimano RT10; 160mm rotor |
| Rear Brake: | Shimano 105; Hydraulic disc brake caliper with Shimano RT10; 160mm rotor |
| Brake Lever: | Shimano 105 |
| Front Mech: | Shimano 105 |
| Rear Mech: | Shimano 105; GS |
| Shifters: | Shimano 105 disc |
| Speed: | 24 |
| Rims: | Merida Expert SL; 17mm inner rim width; 22mm rim depth; aluminium |
| Front Hub: | Shimano HB-TC500; 100 x 12mm; 28 spoke; Centerlock |
| Rear Hub: | Shimano FH-TC500-HL; 142 x 12mm; 28 spoke; Centerlock |
| Spokes: | Double Butted Black stainless |
| Front Tyre: | Continental Ultra Sport III; 700 x 28C; Kevlar bead |
| Rear Tyre: | Continental Ultra Sport III; 700 x 28C; Kevlar bead |
| Seat Post: | Merida Expert CC; 27.2mm diameter; 15mm layback; Carbon |
| Saddle: | Merida Expert SL; V-mount; including Merida minitool |
| Chainset: | Shimano 105; FCR7100, 52-36 tooth chainset; Crank length - 165mm (XXS), 170mm (XS), 172.5mm (S/M/L), 175mm (XL) |
| Bottom Bracket: | SM-BB71-41B, Pressfit 86.5 |
| Chain: | Shimano CN-M6100-12 |
| Cassette: | Shimano CS-R7101; 11-34 teeth; 12 speed |
| Pedals: | Resin Platform |
What are the delivery costs?
We offer Free UK Mainland Delivery on all orders over £20. Products shipped to outlying UK regions are excluded from free shipping.
Standard delivery is normally 2 - 5 working days.
Please view our delivery page for full information on UK and international delivery costs.
Entry level lightweight performance carbon road bike. Lightweight CF3 carbon framset with full Shimano 105 groupset and hydraulic disc brakes.
Team Bahrain Victorious put the fifth generation Scultura thoroughly through its paces, winning mountain top stages of the Tour de France and the Vuelta a Espana before the bike was even launched.
Gen 5 keeps the Scultura's fabled lightweight, agility and rider comfort focus and even manages to improve on both measures.
The Scultura now incorporates learnings from the Reacto in terms of aerodynamics; they now share the same race proven geometry.
Improving weight, comfort and aerodynamics requires plenty of engineering ingenuity. Round tubes are lighter than aero profiled tubes, fatter tyres are more comfortable but less aerodynamic. There are always compromises to be made.
The new Scultura is the most aerodynamic ever and shows outstanding compliance, providing class-leading rider comfort. The marketing blurb suggests this helps keep the body fresh for the final sprint or ascent. A couple of mountain top, grand tour stage victories underline that point quite well!
Occasionally, without notice, manufacturers change product design and/or specifications.
