Frame: | Lite Aluminium, Next Generation enduro geometry, internal cable routing, long seat post insert depth. Boost axles standard, threaded BB, trail mount and bottle bosses, flip chip for mullet or 29er. max tyre size - 2.5" |
Fork: | RockShox Domain R; Air; 170mm travel; Tapered; 44mm fork offset; Max tyre size: 29 x 2.8" |
Rear Shock: | RockShox Deluxe Select+; platform |
Headset: | Acros ICR external neck; Upper and lower IPS sealing |
Stem: | Merida Expert eTRII; aluminium; 35mm diameter; 0 degree rise - Stem length: 40mm (all sizes). GoPro & Supernova mount point. |
Bars: | Merida Expert TR II; aluminium; 780mm wide; XS/S 18mm rise; M/L/XL 30mm rise |
Front Brake: | Shimano Deore M6120; 4 piston hydraulic disc brake caliper with Shimano RT30; 203mm rotor |
Rear Brake: | Shimano Deore M6120 4 piston hydraulic disc brake caliper with Shimano RT30 203mm rotor |
Brake Lever: | Shimano Deore M6120 |
Rear Mech: | Shimano Deore M6100 Shadow+; SGS |
Shifters: | Shimano Deore M6100 and Shimano SL-MT500-IL dropper post lever |
Speed: | 12 |
Rims: | Merida Comp TR II; 28mm inner rim width; aluminium; Tubeless ready (tubeless tape and valves not included); Rear 27.5" for XS/S & M, 29" for L & XL |
Front Hub: | Shimano TC500-B; 110x15mm; 32 spokes; Center lock |
Rear Hub: | Shimano TC500-MS-B; 148x12mm, 32 spokes; Center lock. With Merida Comp TR axle including removable lever, 6mm allen key |
Spokes: | Double Butted Black stainless |
Front Tyre: | Maxxis Assegai; 29" x 2.5"; Kevlar bead, folding; TR 3C MaxxGrip |
Rear Tyre: | Maxxis DHR II; 27.5" x 2.4" for XS/S & M; 29" x 2.4" for L & XL; Kevlar bead, folding; TR DD 3C MaxxTerra |
Seat Post: | Merida Expert TR II; 34.9mm diameter; in-line; Drop: 150mm (XS/S), 170mm (M), 200mm (L/XL) |
Saddle: | Merida Comp SL with V-mount |
Chainset: | Shimano MT512; 32 tooth chainset with Merida Expert TR chainguide; crank length: 170mm all sizes |
Bottom Bracket: | Shimano BB-MT-501; 24mm |
Chain: | KMC X12 |
Cassette: | Shimano Deore M6100; 10-51 teeth; 12 speed |
Pedals: | Not included |
